elastic monofilament extrusion Machine

  • Product Name:

    elastic monofilament extrusion Machine

  • Model No:  SYL-T
  •   Skype Me  Email Us
  • elastic yarn
  • elastic monofilament extrusion Machine
  • elastic monofilament extrusion Machine

Detailed Product Description

elastic monofilament extrusion machine.jpg

Applications:elastic monofilament, flywire filament, sheath-core monofilament.

Technical parameter
ItemAbrasive Monofilament Extrusion Machine
Raw MaterialTPU, PET, PA6...
Dia. of monofilament 0.1-0.35mm; 0.35-1.0mm
Dia. of screwØ65-80mm
Heating type of spinneretoil heating, electrical heating
Stretching modehot water, hot wind
Qty. of stretching unit3-4
System installed capacity350KW
Normal operational capacity210KW
Overall size(L×W×H)(40-52m)x 2.8m x 3m
Total weight25-36T

*These data just for reference, exact specs depend on final configuration



  • Special design screw.

  • Automatic adjustment screw speed.

  • Extruder with automatic pressure feedback system to accurately control the output.

  • PID intelligent temperature control.

2. Cooling Water Tank
  • independent heating system.

  • Unique flow channel ensure each yarn running without interference.

3. Stretching Roller Machine
  • Helical gear transmission system with oil bath lubrication reduce the maintenance times and cost.

  • AC Motor complete with AC inverter Drive.

  • All driving rollers with Hard Chromim plated.

  • Ceramics plate also available. It have better anti-corrosion ability.

4. Hot Air Oven
  • Excellent insulated treatment help saving energy and cost

  • Patented air flow designed to ensure consistent temperature and evenly heat distrubution.

  • Doulbe layer oven also available which can heat and stretch the yarn in all around.

  • PID Temperature controller.

5. Winder
  • Various Types can satisfy customers' demands.

  • Linear guideway to control the alternate motion.

▶Service & Advantage

1. Provide the most advanced industry solution.

2. Free consulting for layout of new workshop.

3. Running and test with feeding material before delivery.

4. Could provide the trainning service for your new workers.

5. Could provide the 24 hours video service.
